MOLEX 4 Way Plug Receptacle. Brand New.
 |
MOLEX 4 Way Receptacle - 3-09-1041
save 75%
| Product ID : |
09518-0001 |
| Price : |
0.31 USD
(Change Currency)
|
|
RRP: 1.25 USD
(less discount 0.94 USD)
|
| Availability : |
In Stock |
|
 |
|
|
|
|
|
MOLEX 4 Way Plug Receptacle. Brand New.
|
| Unit Dimensions : | 3.8W x 2.5D x 0.6H cms |
Condition : | New |
| Shipping Weight : | 0.002 kg |
Physical Weight : | 0.002 kg |
| Location : | Australia |
Packing Terms : | Plastic Bag |
| Shipping Terms : | Ex Works |
Product Type : | Connectors and Plugs |
- RECEPTACLE, 0.093" 4WAY
- Ways, No. of:4
- Area, wire size min:0.597mm�²
- Area, wire size max:1.68mm�²
- Colour:Clear
- Diameter, cable max:4.06mm
- Current rating:9A
- Flammability rating:UL94V-2
- Material:Nylon
- Poles, No. of:4
- Temp, op. max:105�°C
- Temp, op. min:-40�°C
- Voltage rating, AC:250V
- Voltage, withstand:3mV
- Voltage, working:250V
- Cut-out size, panel:26.37x7.92mm
- Dielectric strength:1500V/m
- Dielectric strength, VAC:1500V
- Force, de-mating:0.027N
- Force, mating:0.034N
- Housing type:Receptacle
- Pitch:5.03mm
- Pitch, lead:5.03mm
 |
| MOLEX 4 Way Receptacle - 3-09-1041 - Connector |
|---|
|
